160x320mm P4 P5 P6 Advertising LED Display Screen Outdoor SMD1921
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | King VisionLed |
| Certification: | CE, ROHS, ISO 9001, UL |
| Model Number: | P8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 6 Square Meters |
|---|---|
| Price: | $985.00/Square Meters 6-49 Square Meters |
| Packaging Details: | Flight case:530mmx650mmx1000mm, 6 pcs panels or 8 pcs panels packed in 1 flight case |
| Delivery Time: | 15 working days |
| Payment Terms: | D/A, D/P, T/T, Western Union, L/C, MoneyGram |
| Supply Ability: | 1000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor Building / Gymnasium / Real Estate/, Outdoor Advertising Led | Name: | Advertising LED Display Screen |
|---|---|---|---|
| Weight Of Cabinet: | 45KG/Pieces | Driving Method: | 1/8 Scan |
| Warranty: | 3 Years | IP Waterproof: | Front: IP67; Back: IP65 |
| High Light: | 160x320mm Advertising LED Display Screen,SMD1921 Advertising LED Display Screen,P4RGB Outdoor Fixed LED Display |
||
Product Description
160*320mm LED Screen P4 P5 P6Outdoor Advertising LED Display Screen SMD1921
The 160*320mm P4RGB module is the replacement for P10 LED Screen also. It's with same size as P10 LED,
but with more dense LED arrangement which makes the LED Signs is more clear than P10 LED Display. The LED
Screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and
blind dots. The LED Screen is with IP65 waterproof and dust proof cabinet design, and with super high brightness
LED, so it works well in rain and sunshine day. With lock design, it can be installation friendly as well.
Features:
1: Module size for P4RGB LED module is 160*320mm
2: High brightness 5000mcd which can be seen in daytime
3: Programmable software, support world language text, photos and video.
4: UL Certified Meanwell power supply has been used to make sure realiable quality.
5: Standard steel cabinet with easy installation design, maintenance from back side. Available for aluminum cabinet
if needed
6: Standard cabinet size: 640*640mm, 960*960mm, welcome for customized size.
| Advertising LED Display Screen | P4 | P5 | P6 | P8 | P10 |
| Pixel Pitch(mm) | 4 | 5 | 6.67 | 8 | 10 |
| LED Chips | SMD1921 | SMD2525 | SMD3535 | SMD3535 | SMD3535 |
| Pixel density(dots/m2) | 62500 | 40000 | 22477 | 15625 | 10000 |
| Driving Method | 1/10 scanning | 1/8 scanning | 1/6 scanning | 1/5 scanning | 1/2 scanning |
| Module Size(mm) | 320*160 | 320*160 | 320*160 | 320*160 | 320*160 |
| Module Resolution | 80*40 | 64*32 | 48*24 | 40*20 | 32*16 |
| Cabinet Size( W*L mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
| Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
| Cabinet Weight( Kg/m2 ) | 35 | 35 | 35 | 35 | 35 |
| Max.Consumption(W/m2) | 800 | 800 | 800 | 800 | 800 |
| Ave.Consumption(W/m2) | 350 | 350 | 350 | 350 | 350 |
| Brightness( Nits ) | ≥5500 | ≥5000 | ≥5500 | ≥5800 | ≥6000 |
| Viewing Angle (Vertical / Horizontal) | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° | 120° / 120° |
| Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz | ≥1920Hz |
| IP Level | IP65 | IP65 | IP65 | IP65 | IP65 |
Advertising LED Display Screen Our service:
1. Any inquiry or complaint will be replied within 24hrs.
2. Providing competitive products and sales consultation.
3. Any your customized product or idea we can help you to design and put into product.
4. Three-year quality guarantee, only needs to anew purchase the raw material when over the warranty period.
5. Protection of your sales area, ideas of design and all your private information.
6.Years of production experience we can very good to control the quality of the product, OEM and ODM accepted
