CCTV Cameras Advertising LED Billboard Steel Structure P8 Outdoor 45m Powder Coating

CCTV Cameras Advertising LED Billboard Steel Structure P8 Outdoor 45m Powder Coating

Product Details:

Place of Origin: Guangdong, China
Brand Name: King VisionLed
Certification: CE, ROHS, ISO 9001, UL
Model Number: P8

Payment & Shipping Terms:

Minimum Order Quantity: 6 Square Meters
Price: $985.00/Square Meters 6-49 Square Meters
Packaging Details: Flight case:530mmx650mmx1000mm, 6 pcs panels or 8 pcs panels packed in 1 flight case
Delivery Time: 15 working days
Payment Terms: D/A, D/P, T/T, Western Union, L/C, MoneyGram
Supply Ability: 1000 Square Meter/Square Meters per Month
Get Best Price Contact Now

Detail Information

Application: Outdoor Building / Gymnasium / Real Estate/, Outdoor Advertising Led Name: Advertising LED Display Screen
Weight Of Cabinet: 45KG/Pieces Driving Method: 1/8 Scan
Warranty: 3 Years IP Waterproof: Front: IP67; Back: IP65
High Light:

CCTV Advertising LED Billboard

,

Powder Coating Advertising LED Billboard

,

P8 Advertising LED Display Screen

Product Description

CCTV Cameras Led Billboard Customized Steel Structure P8 Outdoor 45m Powder Coating



Detail of Advertising LED Display Screen :

Standard P8RGB module size would be 128*256mm, and ours is 160*320mm, it would be same size as P10RGB LED

Screen and with better resolution. SMD3535 LED with high brigtness, makes the LED Display is visable in daytime and

100m distance. With fast installation design, programmable software, the billboard led screen is widly used in advertising,

sports, industrial enterprise, transportation, stations, terminals, airports, construction, education system and other public places.



Features:

1: Module size 160*320mm, same as P10 LED module.

2: Steel cabinet with back door, IP65 Waterproof LED Dispay.

3: SMD3535 LED, high brightness up to 6000mcd/square meter

4: Standard cabinet size is 960*960mm, Customized size is welcomed.

5: Manual adjustable brightness (optional for automatically adjust with brightness sensor)
6: 2 year limited warranty and lifetime technical support
7: Standard cabinet size 960*960mm, acceptable for customized size.



Advertising LED Display Screen P4 P5 P6 P8 P10
Pixel Pitch(mm) 4 5 6.67 8 10
LED Chips SMD1921 SMD2525 SMD3535 SMD3535 SMD3535
Pixel density(dots/m2) 62500 40000 22477 15625 10000
Driving Method 1/10 scanning 1/8 scanning 1/6 scanning 1/5 scanning 1/2 scanning
Module Size(mm) 320*160 320*160 320*160 320*160 320*160
Module Resolution 80*40 64*32 48*24 40*20 32*16
Cabinet Size( W*L mm) 960*960 960*960 960*960 960*960 960*960
Cabinet Material

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Cabinet Weight( Kg/m2 ) 35 35 35 35 35
Max.Consumption(W/m2) 800 800 800 800 800
Ave.Consumption(W/m2) 350 350 350 350 350
Brightness( Nits ) ≥5500 ≥5000 ≥5500 ≥5800 ≥6000
Viewing Angle (Vertical / Horizontal) 120° / 120° 120° / 120° 120° / 120° 120° / 120° 120° / 120°
Refresh Rate ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz
IP Level IP65 IP65 IP65 IP65 IP65



CCTV Cameras Advertising LED Billboard Steel Structure P8 Outdoor 45m Powder Coating 0CCTV Cameras Advertising LED Billboard Steel Structure P8 Outdoor 45m Powder Coating 1CCTV Cameras Advertising LED Billboard Steel Structure P8 Outdoor 45m Powder Coating 2

Advertising LED Display Screen Our service:

Q1: What's the difference for P8 128*256 modules and 160*320 led module?
A1: 128*256 and 160*320 P8 LED module display, they are same, just difference in size. They will be used in
different requirements. If display size is the times for 160*320modules, then we will use this model, or it would
be the normal 128*256 P8 LED.
Q2: What kind of video format can be shown? Can it support real time showing?
A2: The outdoor scrolling led sign can support regular format video like MP4, AVI, WMV etc. Normally it's asynchronize
program, it's optional for sychronize content (real time showing), please contact us before production.
Q3: How far for the control distance for WIFI?
A3: DL outdoor led display panels is with POE WIFI router, which would provide you long transmission distance than
normal led, up to 200m in empty area.
Q4: Any after-sale service for your Outdoor LED Screen?
A4: We have a strong customer service team, provide you 7x24hours support.
For software problem, we will assist you by remote like teamviewer, anydesk.
If firmware problem, shall send you video to do repairing.
