High Definition Thin 8K Led Video Wall Hire 1.875mm Pitch 3840hz High Refresh Rate
Product Details:
Place of Origin: | Guangdong, China |
Brand Name: | King Visionled |
Certification: | CE, CCC, Rohs, FCC ISO |
Model Number: | P1.875 |
Payment & Shipping Terms:
Minimum Order Quantity: | Min 6 Square meter |
---|---|
Price: | USD 1,550.00- 2,000.00/SQM |
Packaging Details: | Carton box, Plywood case or flight case, Single package size is 84X68X38 cm about 50kg |
Delivery Time: | 15 Working days |
Payment Terms: | D/P, T/T, L/C, D/A |
Supply Ability: | 1000 sqm / month |
Detail Information |
|||
Place: | TV Station,control Room,command Center Etc, | Panel Size: | 480x480mmx57mm |
---|---|---|---|
Module Size: | 160mm*160mm | Refresh Rate: | 3840Hz |
Type Name: | 8K LED Video Wall | Installation Type: | Front&Rear Installation |
High Light: | HD Thin 8K Led Video Wall,P1.875mm led wall display screen,8K Led Video Wall Hire 3840hz |
Product Description
High Definition Thin 8K Led Video Wall Hire 1.875mm Pitch 3840hz High Refresh Rate
8K LED Video Wall Product Description
1. The effect is excellent: the use of dynamic scanning technology, the picture is stable, no noise, the image effect is clear, the animation effect is vivid and diverse, the video effect is smooth and realistic;
2. Rich in content: can display text, graphics, images, animations, video information;
3. Flexible mode: Users can arrange display modes arbitrarily;
4. Cabinet customization: the cabinet supports custom size;
5. Excellent perspective: Both horizontal and vertical angles are large, suitable for environments with wide horizontal distribution and high height difference;
6. High reliability:using distributed scanning technology and modular design technology, reliability and stability are higher;
7. Quality Assurance: Imported luminescent materials, high quality IC chips, no noise and high power supply; tensile and shockproof, long service life of 10 years;
8. Convenient maintenance: modular design, easy installation and maintenance
4K 8K LED Video Wall of Technical Parameter
Parameter | P1.875mm HD LED Screen | P2.5mm HD LED Video wall |
Pixel Pitch | 1.875mm | 2.5mm |
Pixel Configuration | SMD 3-IN-1 | SMD2121 3-IN-1 |
Pixel Density | 284,089 dots/m² | 160,000 dots/m² |
Module size | 240x240mm | 240x240mm |
Cabinet Size | 480x480mmx57mm | 480x480mmx57mm |
Panel Dimension (WxHxD) | 18.9''X18.9''X3'' | 18.9''X18.9''X3'' |
Panel Material | Die-casting Aluminum | Die-casting Aluminum |
Panel Weight | 4.9kg/panel (10.8lb/panel) | 6.8kg/panel (15lb/panel) |
Refresh Rate | 1920Hz~3840Hz | 1920Hz~3840Hz |
Brightness | 1000nits(Adjustable) | 1200nits(Adjustable) |
Horizontal Viewing Angle(°) | 160 ° | 160 ° |
Vertical Viewing Angle(°) | 160 ° | 160 ° |
AC Power Input(V) | AC110V~ 220V ±10% | AC110V~ 220V ±10% |
AC Power Frequency(Hz) | 50 ~ 60 Hz | 50 ~ 60 Hz |
Max. Power(W/m²) | 565 W/m² | 520 W/m² |
Avg. Power(W/m²) | 189 W/m² | 170 W/m² |
Storage/Operating Humidity(RH ) | 10% ~ 90%RH | 10% ~ 90%RH |
IP Rating(IP ) | IP30 / IP30 | IP30 / IP30 |
Lifetime Typical Value(Hrs) | 100,000 Hrs | 100,000 Hrs |
Installation Type | Front&Rear installation | Front&Rear installation |
Maintenance Method | Front&Rear Access Maintenance | Front&Rear Access Maintenance |
Product Details & Application
1.Magnetic Module with frame-sharing 480x480mm die-casting aluminum cabinets
2. Friendly Cabinet design with comfortable rounded corner handle,heat emission holes,signal indicator testing button,OEM Label, Anti-collision corner,Hidden cables design and front maintenance tool design.
3.Free-structure Install, flexible for wall mounted fixed and saving installation cost and space
4.Wide application indoor stage rental or indoor advertising or presentation
8K Led Video Wall Our service:
We provide free and timely after-sales service including remote control technical advice difficult to solve the problem;
During the warranty period all rework services are free;
We can arrange for the engineer to the site to guide the installation and free training.
