P2.5 Led Panels 480x480mm For Video Wall Screen 8K High Definition Indoor LED Video Wall
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | King Visionled |
| Certification: | CE, CCC, Rohs, FCC ISO |
| Model Number: | P2.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min 6 Square meter |
|---|---|
| Price: | USD 1,550.00- 2,000.00/SQM |
| Packaging Details: | Carton box, Plywood case or flight case, Single package size is 84X68X38 cm about 50kg |
| Delivery Time: | 15 Working days |
| Payment Terms: | D/P, T/T, L/C, D/A |
| Supply Ability: | 1000 sqm / month |
|
Detail Information |
|||
| Application: | TV Station,control Room,command Center Etc, | Product: | 8K LED Video Wall |
|---|---|---|---|
| Pixel: | 2.5mm | Brightness: | 1500cd/㎡ |
| High Solution: | 3840Hz | Cabinet Level Up Degree ( Mm ): | 0.2 |
| Installation Type: | Front&Rear Installation | ||
Product Description
P2.5 Led Panels 480x480mm For Video Wall Screen 8K High Definition Indoor LED Video Wall
4K 8K LED Video Wall Applications:
1)With good lightening accordance and no mosaic.
2)Can play different formats of image files, flash, video signal from TV, video and other equipments.
3)Different video frequency can be changed freely at the same time, and the image can be enlarged and shrinked.
4)High brightness, and can be adjustable, meets the needs of customer's requirements.
5)Uses real pixels rather than virtual pixcels, better viewing effect .
6)With the best quality IC MBI5153, refresh rate can be reached 3840HZ, and show you the perfect visual effect.
7)The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.
4K 8K LED Video Wall of Technical Parameter
| Parameter | P1.875mm HD LED Screen | P2.5mm HD LED Video wall |
| Pixel Pitch | 1.875mm | 2.5mm |
| Pixel Configuration | SMD 3-IN-1 | SMD2121 3-IN-1 |
| Pixel Density | 284,089 dots/m² | 160,000 dots/m² |
| Module size | 240x240mm | 240x240mm |
| Cabinet Size | 480x480mmx57mm | 480x480mmx57mm |
| Panel Dimension (WxHxD) | 18.9''X18.9''X3'' | 18.9''X18.9''X3'' |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum |
| Panel Weight | 4.9kg/panel (10.8lb/panel) | 6.8kg/panel (15lb/panel) |
| Refresh Rate | 1920Hz~3840Hz | 1920Hz~3840Hz |
| Brightness | 1000nits(Adjustable) | 1200nits(Adjustable) |
| Horizontal Viewing Angle(°) | 160 ° | 160 ° |
| Vertical Viewing Angle(°) | 160 ° | 160 ° |
| AC Power Input(V) | AC110V~ 220V ±10% | AC110V~ 220V ±10% |
| AC Power Frequency(Hz) | 50 ~ 60 Hz | 50 ~ 60 Hz |
| Max. Power(W/m²) | 565 W/m² | 520 W/m² |
| Avg. Power(W/m²) | 189 W/m² | 170 W/m² |
| Storage/Operating Humidity(RH ) | 10% ~ 90%RH | 10% ~ 90%RH |
| IP Rating(IP ) | IP30 / IP30 | IP30 / IP30 |
| Lifetime Typical Value(Hrs) | 100,000 Hrs | 100,000 Hrs |
| Installation Type | Front&Rear installation | Front&Rear installation |
| Maintenance Method | Front&Rear Access Maintenance | Front&Rear Access Maintenance |
