3.91mm P5 Led Module Outdoor Electronic Billboard Die Casting Aluminum Led Cabinet
Product Details:
Place of Origin: | Guangdong, China |
Brand Name: | King VisionLed |
Certification: | CE, ROHS, ISO 9001, UL |
Model Number: | P3.91 |
Payment & Shipping Terms:
Minimum Order Quantity: | 8 Square Meters |
---|---|
Price: | $780.00/Square Meters 8-49 Square Meters |
Packaging Details: | Flight case:530mmx650mmx1000mm, 6 pcs panels or 8 pcs panels packed in 1 flight case |
Delivery Time: | 15 working days |
Payment Terms: | D/A, D/P, T/T, Western Union, L/C, MoneyGram |
Supply Ability: | 1000 Square Meter/Square Meters per Month |
Detail Information |
|||
Cabinet Size: | 500x1000mm | Pixel Pitch: | 3.91mm |
---|---|---|---|
Function: | Outdoor Rental Led Display | Software Environment: | WindowsNT,Windows1999,WindowsXP |
Mean Time Between Failure: | >5000hours | Port: | Shenzhen |
High Light: | 3.91mm P5 Led Module Outdoor,3.91mm Die Casting Aluminum Led Cabinet,outdoor electronic display board |
Product Description
Outdoor Rental Led Display P3.91/P4.81 Die-Casting Aluminum 500x1000mm For Event Stage
Detail of Outdoor Rental Led Display:
1. Seamless splicing, could be adjusted, more easy to maintain.
2. Low noise, low consumption, ensure the long lifespan.
3. Die-casting aluminum panel of great dissipation could save your electricity cost substantially.
4. High quality LED chip,wide viewing angle,good flatness,anti-static,high brightness, low attenuation,good stability.
5. Adopts 500x1000mm cabinet size,fast installation,vivid image display with wide viewing angle. Varieties of display mode, easy to operate.
6. Standard cabinet design,to make the same cabinet size can apply to different pixel display.Therefore,it’s more convenient to install and dismantle for the whole screen. Lightweight cabinet design, save transportation cost.
7. Also can make with P3.9 Indoor, P3.9 outdoor, P4.81 outdoor rental LED display.
Outdoor Rental Led Display | KL 1 Series | KL2 Series | KL3 Series |
Pixe Pictch | 3.91mm | 3.91mm | 4.81mm |
Led encapsulation | SMD2121 | SMD1921 | SMD1921 |
Scan Mode | 1/16 Scan | 1/16 Scan | 1/13 Scan |
Pixe Per Sq.m | 65536 Pixel | 65,536 Pixel | 43,264 Pixel |
Brightness(Nits/㎡) | 1100 Nits | 4500 Nits | 4500 Nits |
IP Protection | IP43 | IP65 | IP65 |
Maintenance Methods | Rear Serviceable | ||
Cabinet Material | Die Casting Aluminum | ||
Module Size(W*H) | 250mm*250mm | ||
Cabinet Size(W*H*D) | 500mm*500mm/500mm*1000mm | ||
Refresh Rate | 3840Hz | ||
Color temperature | 9500K ±500(Adjustable) | ||
Grey Scale | 14-16Bit | ||
Cabinet Weight | 7KG/12KG | ||
Average Power Consumption | 350-400Watt/㎡ | ||
Max Power Consumption | 800Watt/㎡ | ||
Operating Temperature | -20°C to 50°C | ||
Curved Angle | ±15 Degrees |
Outdoor Rental Led Display FAQ:
Q1: Can the LED display screen work when lightning?
If necessary, users have to install surge switches in the distribution box and ground fault protection to avoid lightning strikes. Do not use the display in strong lightning and other severe weather.
Q2: Can the LED display screen display long time in one kind of color?
Do not display a long time in a white, red, green, blue or other bright screen, because this will affect the display lifetime.
Q3: How long can the LED display screen display?
LED display at least rest 2 hours a day. Normally turn on the screen at least twice a week or more (Especially in the rainy season it is necessary to turn on the display every day). And it maintains more than 2 hours every time.
